MAMBA Turbocharger Fits For SUBARU BP5 BL5 Legacy Liberty TD04HLX-21TK 380 HP

Item No.: 001-0373
Inventory Status: In Stock

Applicable Promotions

Add to Wishlist Redeemable credit(s) per item 20 credit(s) equivalent to $20.00
Product Information

Product Information



Item Name

MAMBA 9-6 Subaru Legacy Liberty GT BL5 BP5 Extreme TD04HLX-21TK-8.5 Twin Scroll Turbocharger


Brand New

Intake system needs to be modified as cover inlet 50.3mm which is larger than factory 45mm.


06~07 Subaru BP5 BP5 Legacy Liberty GT

Replace and upgrade IHI VF38, VF44, VF45

Replace JDM TD04HLA-19T 49189-06500, 49189-06501

HP Support: 280HP~400HP


Compressor wheel : 49.6/61 (6+6 Blade 21TK Billet Compressor Wheel)

Turbine Wheel: 48.1/53.0 (9 Blade Extreme TD04HLX)

Turbine Housing

Twin Scroll 8.5 cm Housing


0.8bar spring will be pre-installed on the adjustable actuator
Additional 1.2bar and 1.5bar spring will go with box

Bearing / Cooling

Journal Bearing / Performance Thrust Bearing Kit Included
Oil and Water-cooled system

Kit Includes

1 x TD04HLX-21TK Turbocharger

1 x Oil Feed Line Kit

2 x Water Coolant line kit

1 x Oil Return pipe kit

1 x Turbine Inlet Gasket

1 x Turbine Outlet Gasket

9 x Stud Kit

Everything shown on first picture is included.


 One year

Made By
