P/N
002- 3165
Item Name
MAMBA 7+7 2.5” fits Subaru Bolt-on GTX3076R Ball Bearing Turbocharger
w/ .49 Turbine Housing
Application
Brand New In Box
Ready to work
Support 400~750HP
Max Boost: 3.4Bar / Recommend 1.5~1.8bar for daily street car.
GC8 / GDA / GDB EJ20 EJ25 turbo with single scroll turbo
Spec
Compressor Wheel: 58/76.6/Trim 58 (7+7 Performance Billet Wheel with Extend Tip)
Turbine Wheel: 55.0/60.0mm (Performance 9 Blade)
Compressor Housing Inlet OD: 2.5” (63.5mm)
Compressor Housing Outlet OD: 2” (51mm)
Compressor Housing A/R: .60
Turbine Housing A/R: .49
Bearing
Ceramic Dual Ball Bearing (NTN JAPAN)
Cooling
Oil & Water-Cooling
Actuator
0.8bar yellow spring is pre-installed on the adjustable actuator
Additional 1.2bar (Black) and 1.5bar (Blue) springs go with box.
Kit Includes
1 x MAMBA 2.5” GTX3076R Ball Bearing Turbocharger
1 x 2.5” Intake Silicon Hose Kit
1 x PTFE Turbo Oil feed line kit
2 x PTFE Turbo Water Line Kit
1 x Turbo Oil Return Line Kit
2 x Turbine Inlet & Outlet Gasket
1 x Vacuum Hose Kit
1 x 12mm to 4AN adapter (Convert Factory M12x1.0 adapter to 4AN that connects PTFE Line)
8 x Forged SCM415 Stud Kit with Copper Nut
Made By
MAMBATEK
Warranty
Please refer to “About us”
